High speed arm type wrapping machine

High speed arm type wrapping machine

High speed arm type wrapping machine have two film carriage and efficiency of work is much more fast,angle bead device can be optional and can increase the function of top pressing and film
products

details

Suitable for large volume and weight goods. Double head rocker increases a cantilever on the basis of single arm winding, and the working efficiency has been greatly improved. With the same winding requirements, the time is almost half saved, which is a rare winding tool for many enterprises with high requirements of assembly line operation

Related

parameters

Model Parameters
Speed 0-60RPM(Adjustable)
Maximum wrapping speed 30-60 loads/hour
Maximum pallet size 1.1*1.2 m
Maximum Wrapping Height 2000mm
Max Load Weight 2000KG
Power Supply 380V 50HZ
Power 7.5KW
Machine Size L4300xW2320xH3530mm
Machine Weight 2500Kg
Standard Pre-Stretch 250-300%
Standard Film Width 500mm
Air 1000ml/min
Pressure 0.4-0.6MPa
