Online wrapping machine

Online wrapping machine

Online wrapping machine.It is suitable for the production line of large volume of fully automated wrapping packaging system equipment


Output wrapping capacity of 15-40 pallets per hour
Fast replacement of wrapping film, saving consumption
Modular design, upgrade at any time according to demand
Intuitive and easy to understand operation interface
Large bearing weight, the standard bearing capacity of 2 tons
Equipment can accept customer's customized requirements



Item Parameter
Roller length 1100/1250/1300mm/ Customizable
Table rotation diameter 2130(Lr=1100)/2200(Lr=1300)mm/ Customizable
Load weight 1500/2000/2500kg/ Customizable
Table rotation speed 5~20Rpm
Carriage up-down speed 2.5~7m/min
Film tensioning Adjustable by touch screen
Film pre-stretch 125~400%
Maximum pallet dimensions L*W 1000~1300*1000~1300mm/ Customizable
Maximum product height 2200/2400/2700/3000mm/ Customizable
Power supply 380V/3P±10% PE /50 or 60Hz
Installed power 2.5/3.0/3.5/4.0Kw
Table working height 350~650mm/ Customizable
Weight of film reel 15/20/25Kg
Film thickness 17~35um
