Automatic top sheet wrapping machine

Automatic top sheet wrapping machine

Automatic top sheet wrapping machine is a kind of wrapping machine which integrates the laminating machine and the automatic wrapping machine to design two functions of wrapping and top cover film pneumatic device clip film, Automatic film breaking and welding film, The welding place is stable without film tail make the film stick to the goods effectively, Prevent the film from loosening.Can match the conveyor line, Docking before and after the online signal, to achieve automatic packaging. Fully automatic pre-stretch pallet film wrapper machine with top sheet dispenser docking before and after the online signal, to achieve automatic packaging plc programmable control, winding top and bottom parameters can be set times photoelectric system to measure the height of cargo automatically. Contact Dyehome for details and price
Get a Quote
Product details


Item

Parameter

Turntable diameter:

1800mm

Packing high:

2000mm

Packaging size:

1200*1200mm/ L*W

Bearing:

2000Kg

Turntable high:

85mm

Speed:

0~12 Rpm

Packing efficiency:

30~50 Pallet/Hour

Film pre-stretch

150-250%

Film tensioning

Adjustable by touch screen

Reel film size

500*260 mm

Weight of film reel

15Kg

Film thickness

17~35 um

Air

1000 ml/min

Pressure

0.4-0.6 Mpa

Width of the top sheet film

1650 mm

Roller width

1300 mm

Roller diameter

89 mm
