L type semi-automatic corner edge carton sealer

L type semi-automatic corner edge carton sealer

Accurate positioning two-way L type semi-automatic corner edge carton sealer, speed variable frequency adjustable, easy to understand the operation
video
products

details


Automatic Corner Sealing Machine Is Made By Manually Adjusting The Carton Size, And The Machine Automatically Realizes The Four-side Sealing Cartons

All details and parts are produced by automatic processing equipment with high precision and quality

Nose propulsion with 90° steering

Perfect Corner Sealing without Drape, Suitable for External Packaging High Requirements of Customers.

Adjust height and width manually when changing specifications

Can be matched with other types of sealing machine, at the same time multi-angle sealing once completed

Equipped with Blade Protection Device to Avoid Accidental Stab Injury During Operation

The structure of the tape is precise and strong, the operation is smooth and the service life is long

All products and details can accept non - standardized customization



Related

parameters

Model
Parameters
Transport velocity
6-10 C/M
Maximum carton size
L700*W500*H500mm
Minimum carton size
L340*W200*H180mm
Power Supply
220V / 380V 50HZ
Power
0.6KW
Atmospheric pressure
6kg/c
Air consumption
100nl/min
Adhesive Tape Width
W48 or 60 or 75mm
Machine Size
L1910xW1150xH1500mm
Machine Weight
440Kg
