Automatic cover carton sealer

Automatic cover carton sealer

Automatic cover carton sealer suitable for the use of various specifications of carton at the same time, automatic size adjustment when changing specifications, using belt drive, can pack 900 cases/hour
video
products

details

Suitable for cartons of various specifications at the same time

Can be used with the conveyor line or single machine operation, automatically fold the cover, the next time to complete

Automatic adjustment of width and height when changing specifications

The standard conveying height is 600 mm, and custom production is acceptable

The transmission mode is driven by belt on both sides

The structure of the belt is precise and strong, the operation is smooth, and the service life is long

Related

parameters

Model
Parameters
Transport velocity
20m/min
Maximum carton size
L600*W500*H500mm
Minimum carton size
L280*W200*H150mm
Power Supply
380V 50HZ
Power
0.4KW
Atmospheric pressure
6kg/c
Air consumption
100nl/min
Adhesive Tape Width
W48 or 60 or 75mm
Machine Size
L1700xW920xH1450mm
Machine Weight
280Kg
