E-commerce type case erector

E-commerce type case erector

E-commerce type case erector suitable for the express industry of small carton forming back cover, can store cartons at the same time to replenish without stopping
video
products

details


Adopt cylinder forming mechanism
Suitable for pack of the same specification
Empty cartons can be replenished at any time
Height of standard machine surface is 650mm
Forming speed depends on the size of the carton
Standard models are directly applicable to 5#-10#
Suitable for e-commerce small size carton molding
With tape and carton lack of material reporting function
Equipped with production line or single machine operation


Related

parameters

Model
Parameters
Carton Opening Speed
8-10 ctns/min
Carton Size Range
L130-300xW90-200xH90-200mm (135≤W/2+H≤400,250 L+W≤550)
Power Supply
220V / 380V 50HZ
Power
0.4KW
Adhesive Tape Width
W48mm
Air consumption
450NL/min
Atmospheric pressure
6kg/c
Machine Size
L1900xW1950xH1450mm
Machine Weight
400Kg
