Low speed case erector

Low speed case erector

Low speed case erector.Automatic carton unpacking machine with standard function, cylinder forming mechanism, forming speed according to the size of the carton, can be customized according to customer needs
video
products

details


Adopt cylinder forming mechanism
Height of the standard machine is 650mm
Suitable for pack of the same specification
Nailing head structure is precise and strong
Empty cartons can be replenished at any time
Nails and carton lack of material alarm function
Equipped with production line or single machine operation
Forming speed depends on the size and the number of nails


Related

parameters

Model
Parameters
Carton Opening Speed
8-10 ctns/min
Carton Size Range
L280-500xW160-400mm (300≤W/2+H≤620,510≤ L+W≤1000)
Power Supply
220V / 380V 50HZ
Power
0.4KW
Adhesive Tape Width
W48mm,60mm,75mm
Air consumption
450NL/min
Atmospheric pressure
6kg/c
Machine Size
L2050xW1950xH1450mm
Machine Weight
400Kg
