Medium speed case erector

Medium speed case erector

Medium speed case erector automatically complete the unpacking, forming, bottom leaf folding and bending, and finish the lower part of the tape paste, the box board folded into cardboard automatically opened, the bottom of the box closed according to a certain procedure, and sealed with tape to the special equipment of the packing machine.
products

details


Adopt cylinder forming mechanism
Height of the standard machine is 650mm
Suitable for pack of the same specification
Nailing head structure is precise and strong
Empty cartons can be replenished at any time
Nails and carton lack of material alarm function
Equipped with production line or single machine operation
Forming speed depends on the size and the number of nails


Model
Parameters
Carton Opening Speed
15-16 ctns/min
Carton Size Range
L280-480xW1650-350mm(300≤W/2+H≤620, 300L+W≤620)
Power Supply
380V 50HZ 3PH
Power
0.4KW
Adhesive Tape Width
W48 / 60 / 75mm
Air consumption
450NL/min
Atmospheric pressure
6kg/c
Machine Size
L2500xW1950xH1450mm
Machine Weight
550Kg
