Winding box sealing machine

Winding box sealing machine

Adopt unique belt replacement structure, effectively improve the machine performance and production efficiency. With the winding sealing method, the work that used to require three devices can now be completed by only one device.


It is economical, fast and easy to adjust. It can complete the top sealing action at one time.
The side sealing mode of detachable conveyor belt is selected, especially suitable for foam boxes.
If equipped with tape printing equipment, can improve the appearance of the product image.



Mode DH-570
Power AC220V/50~60Hz
Voltage 1000W
Speed 16C/min
Width 48mm  60mm
Move type L.R. Conveyor belt drive
Max size(L×W×H) 490×310×245mm
Min size(L×W×H) 225×125×150mm
Machine size(L×W×H) 2086×1362×1420
BROCHURE download


  • *
  • *
  • *
  • *
